S202 Single channel Algorithm Camera

The S202 is a professional-grade in-vehicle AI safety terminal, integrating intelligent video encoding, 4G full-network transmission, and dual AI vision algorithms (DMS driving behavior monitoring/BSD blind spot detection). It provides fleet safety management with an integrated solution encompassing all-weather high-definition video surveillance, proactive safety warnings, and remote vehicle control.

1. High-Definition Intelligent Imaging System

• Dual 1080P High-Definition Recording: Employs H.265 intelligent encoding, providing smooth 30fps video playback, and supports 1-8 levels of image quality adjustment.

• Dual-Mode Night Vision: Optional infrared or white light supplementary illumination ensures clear monitoring in nighttime and low-light environments.

• Audio and Video Synchronization: Built-in microphone and 2W speaker support two-way voice communication and monitoring.

2. 4G Full Network Compatibility + High-Precision Positioning

• CAT1 4G Full-Band Compatibility: Covers major global networks in Europe and Latin America, ensuring stable data transmission.

• Beidou/GPS Dual-Mode Positioning: Built-in high-precision positioning module for real-time tracking and trajectory playback.

• Remote Upgrade and Management: Supports FTP remote firmware upgrades and multi-terminal control via APP/client/platform.

3. AI Active Safety Warning (Optional)

• DMS Driver Monitoring: Real-time identification of dangerous behaviors such as fatigued driving, distracted driving, smoking, and obstructing cameras.

• BSD Blind Spot Detection: Accurately detects pedestrians and vehicles, reducing the risk of accidents in blind spots. Intelligent Alarm Linkage: Supports ADAS algorithm expansion, providing warnings for forward collisions, lane departures, etc.

4. Professional-Grade Vehicle Expansion and Control

• Dual I/O Interfaces + RS232 Serial Port: Supports external sensors and relays for remote fuel and power cut-off control.

• Large-Capacity Local Storage: Supports up to 512GB TF cards, ensuring data security.

• Wide Voltage Power Supply Protection: Supports 9-36V DC input, with overload, short circuit, and reverse connection protection.

5. Industrial-Grade Protection and Standard Certification

• Wide Temperature Range Operation: Stable operation in extreme environments from -30℃ to +70℃.

• IP67 Waterproof and Dustproof: Adaptable to various harsh vehicle environments.

Applicable Scenarios: Logistics fleets, passenger buses, hazardous materials transportation, construction machinery, ride-hailing vehicle management, etc.

Through AI visual algorithms and multiple safety early warning mechanisms, this terminal helps companies reduce accident rates, optimize driving behavior, and achieve a closed-loop digital fleet safety management system.
